ioLogik E2200 Series Modbus/TCP Address Mappings
I-71
Reference Address Data Type Description
40250 0x00F9 1 word CH1 DI set/get power on start word
40251 0x00FA 1 word CH2 DI set/get power on start word
40252 0x00FB 1 word CH3 DI set/get power on start word
40253 0x00FC 1 word CH4 DI set/get power on start word
40254 0x00FD 1 word CH5 DI set/get power on start word
40255 0x00FE 1 word CH6 DI set/get power on start word
40256 0x00FF 1 word CH7 DI set/get power on start word
40257 0x0100 1 word CH8 DI set/get power on start word
40258 0x0101 1 word CH9 DI set/get power on start word
40259 0x0102 1 word CH10 DI set/get power on start word
40260 0x0103 1 word CH11 DI set/get power on start word
40261 0x0104 1 word CH0 DI set/get safe start word
40262 0x0105 1 word CH1 DI set/get safe start word
40263 0x0106 1 word CH2 DI set/get safe start word
40264 0x0107 1 word CH3 DI set/get safe start word
40265 0x0108 1 word CH4 DI set/get safe start word
40266 0x0109 1 word CH5 DI set/get safe start word
40267 0x010A 1 word CH6 DI set/get safe start word
40268 0x010B 1 word CH7 DI set/get safe start word
40269 0x010C 1 word CH8 DI set/get safe start word
40270 0x010D 1 word CH9 DI set/get safe start word
40271 0x010E 1 word CH10 DI set/get safe start word
40272 0x010F 1 word CH11 DI set/get safe start word
40273 0x0110 1 word CH0 Power-off storage enable
40274 0x0111 1 word CH1 Power-off storage enable
40275 0x0112 1 word CH2 Power-off storage enable
40276 0x0113 1 word CH3 Power-off storage enable
40277 0x0114 1 word CH4 Power-off storage enable
40278 0x0115 1 word CH5 Power-off storage enable
40279 0x0116 1 word CH6 Power-off storage enable
40280 0x0117 1 word CH7 Power-off storage enable
40281 0x0118 1 word CH8 Power-off storage enable
40282 0x0119 1 word CH9 Power-off storage enable
40283 0x011A 1 word CH10 Power-off storage enable
40284 0x011B 1 word CH11 Power-off storage enable
40285 0x011C 1 word AI Channel 0 Scaling Enable
40286 0x011D 1 word AI Channel 1 Scaling Enable
40287 0x011E 1 word AI Channel 2 Scaling Enable
40288 0x011F 1 word AI Channel 3 Scaling Enable
40289 0x0120 1 word AI Channel 0 RAW Min Value
40290 0x0121 1 word AI Channel 1 RAW Min Value
40291 0x0122 1 word AI Channel 2 RAW Min Value
40292 0x0123 1 word AI Channel 3 RAW Min Value
40293 0x0124 1 word AI Channel 0 RAW Max Value
40294 0x0125 1 word AI Channel 1 RAW Max Value
40295 0x0126 1 word AI Channel 2 RAW Max Value
40296 0x0127 1 word AI Channel 3 RAW Max Value
40297 0x0128 1 word AI Channel 0 Scale Min Value
40298 0x0129 1 word AI Channel 1 Scale Min Value
40299 0x012A 1 word AI Channel 2 Scale Min Value
40300 0x012B 1 word AI Channel 3 Scale Min Value
40301 0x012C 1 word AI Channel 0 Scale Max Value
