ioLogik E2200 Series Modbus/TCP Address Mappings
I-73
Reference Address Data Type Description
40514 0x0201 1 word CH1 AI Range
00 : +/-150mV
01: +/-500mV
02: +/-5V
03: +/-10V
04: 0-20mA
05: 4-20mA
06 : 0 -150mV
07 : 0 - 500mV
08: 0 - 5V
09: 0 -10V
Others: return Illegal Data Value
40515 0x0202 1 word CH2 AI Range
00: +/-150mV
01: +/-500mV
02: +/-5V
03: +/-10V
04: 0-20mA
05: 4-20mA
06 : 0 -150mV
07 : 0 - 500mV
08: 0 - 5V
09: 0 -10V
Others: return Illegal Data Value
40516 0x0203 1 word CH3 AI Range
00 : +/-150mV
01: +/-500mV
02: +/-5V
03: +/-10V
04: 0-20mA
05: 4-20mA
06 : 0 -150mV
07 : 0 - 500mV
08: 0 - 5V
09: 0 -10V
Others: return Illegal Data Value
System information (R/W)
41000 0x03E8
(1000)
1 word Load default setting, data=0x0078
44097 0x1000 2 word IP address (need reboot)
Word 0 Hi byte = 192 (0xC0)
Word 0 Lo byte = 168 (0xA8)
Word 1 Hi byte = 15 (0x0F)
Word 1 Lo byte = 1 (0x01)
IP address is “192.168.15.1”
44098 0x1001 2 word Subnet mask (need reboot)
Word 0 Hi byte = 255
Word 0 Lo byte = 255
Word 1 Hi byte = 255
Word 1 Lo byte = 0
Subnet mask is “255.255.255.0”
