ioLogik E2200 Series Modbus/TCP Address Mappings
I-60
Reference Address Data Type Description
00099 0x0062 1 bit CH2 DI OverFlow Status
Read: 0 : Normal
1 : Overflow
Write: 0 : clear overflow status
1 : return Illegal Data Value
00100 0x0063 1 bit CH3 DI OverFlow Status
Read: 0 : Normal
1 : Overflow
Write: 0 : clear overflow status
1 : return Illegal Data Value
00101 0x0064 1 bit CH4 DI OverFlow Status
Read: 0 : Normal
1 : Overflow
Write: 0 : clear overflow status
1 : return Illegal Data Value
00102 0x0065 1 bit CH5 DI OverFlow Status
Read: 0 : Normal
1 : Overflow
Write: 0 : clear overflow status
1 : return Illegal Data Value
00103 0x0066 1 bit CH6 DI OverFlow Status
Read: 0 : Normal
1 : Overflow
Write: 0 : clear overflow status
1 : return Illegal Data Value
00104 0x0067 1 bit CH7 DI OverFlow Status
Read: 0 : Normal
1 : Overflow
Write: 0 : clear overflow status
1 : return Illegal Data Value
00105 0x0068 1 bit CH8 DI OverFlow Status
Read : 0 : Normal
1 : Overflow
Write: 0 : clear overflow status
1 : return Illegal Data Value
00106 0x0069 1 bit CH9 DI OverFlow Status
Read: 0 : Normal
1 : Overflow
Write : 0 : clear overflow status
1 : return Illegal Data Value
00107 0x006A 1 bit CH10 DI OverFlow Status
Read: 0 : Normal
1 : Overflow
Write: 0 : clear overflow status
1 : return Illegal Data Value
00108 0x006B 1 bit CH11 DI OverFlow Status
Read: 0 : Normal
1 : Overflow
Write: 0 : clear overflow status
1 : return Illegal Data Value
00109 0x006C 1 bit CH0 DI Count Trigger
00110 0x006D 1 bit CH1 DI Count Trigger
00111 0x006E 1 bit CH2 DI Count Trigger
