ioLogik E2200 Series Using ioAdmin
3-15
I/O Configuration Tab (Administrator)
When logged in as an administrator, double-click on a channel in the I/O Configuration tab to configure that
channel’s settings. A window will open with configuration options for that channel. After configuraing the
channel as desired, click Apply to implement the new settings.
1. Configuring Analog Input Channels
2. Configuring Analog Output Channels
3. Configuring DIO Channels
4. Configuring Digital Input and Event Counter Channels
5. Configuring Digital Output and Relay output Channels
6. Relay Count Monitoring
7. Testing DI and DO Channels
8. Configuring RTD Channels
9. Configuring TC Channels
NOTE
To show or hide the image of the ioLogik device, right
-click on the ioAdmin window. Selecting Horizontal
View
from the dropdown menu will show the ioLogik’s picture, whereas selecting Vertical View
will hide the
image.
