ioLogik E2200 Series Modbus/TCP Address Mappings
I-24
Reference Address Data Type Description
10010 0x0009 1 bit CH9 DI value
10011 0x000A 1 bit CH10 DI value
10012 0x000B 1 bit CH11 DI value
10013 0x000C 1 bit Non-active
10014 0x000D 1 bit Non-active
10015 0x000E 1 bit Non-active
10016 0x000F 1 bit Non-active
3xxxx Read Only Registers (Function 4)
Reference Address Data Type Description
30001 0x0000 1 word CH0 DI count value hi-byte
30002 0x0001 1 word CH0 DI count value lo-byte
30003 0x0002 1 word CH1 DI count value hi-byte
30004 0x0003 1 word CH1 DI count value lo-byte
30005 0x0004 1 word CH2 DI count value hi-byte
30006 0x0005 1 word CH2 DI count value lo-byte
30007 0x0006 1 word CH3 DI count value hi-byte
30008 0x0007 1 word CH3 DI count value lo-byte
30009 0x0008 1 word CH4 DI count value hi-byte
30010 0x0009 1 word CH4 DI count value lo-byte
30011 0x000A 1 word CH5 DI count value hi-byte
30012 0x000B 1 word CH5 DI count value lo-byte
30013 0x000C 1 word CH6 DI count value hi-byte
30014 0x000D 1 word CH6 DI count value lo-byte
30015 0x000E 1 word CH7 DI count value hi-byte
30016 0x000F 1 word CH7 DI count value lo-byte
30017 0x0010 1 word CH8 DI count value hi-byte
30018 0x0011 1 word CH8 DI count value lo-byte
30019 0x0012 1 word CH9 DI count value hi-byte
30020 0x0013 1 word CH9 DI count value lo-byte
30021 0x0014 1 word CH10 DI count value hi-byte
30022 0x0015 1 word CH10 DI count value lo-byte
30023 0x0016 1 word CH11 DI count value hi-byte
30024 0x0017 1 word CH11 DI count value lo-byte
312289 0x3000 1 word CH0 DI value
312290 0x3001 1 word CH1 DI value
312291 0x3002 1 word CH2 DI value
312292 0x3003 1 word CH3 DI value
312293 0x3004 1 word CH4 DI value
312294 0x3005 1 word CH5 DI value
312295 0x3006 1 word CH6 DI value
312296 0x3007 1 word CH7 DI value
312297 0x3008 1 word CH8 DI value
312298 0x3009 1 word CH9 DI value
312299 0x300A 1 word CH10 DI value
312300 0x300B 1 word CH11 DI value
