ioLogik E2200 Series Modbus/TCP Address Mappings
I-62
Reference Address Data Type Description
00149 0x0094 1 bit CH4 DI set channel
Power-off storage enable ON/OFF
1:ON
0:OFF
00150 0x0095 1 bit CH5 DI set channel
Power-off storage enable ON/OFF
1:ON
0:OFF
00151 0x0096 1 bit CH6 DI set channel
Power-off storage enable ON/OFF
1:ON
0:OFF
00152 0x0097 1 bit CH7 DI set channel
Power-off storage enable ON/OFF
1:ON
0:OFF
00153 0x0098 1 bit CH8 DI set channel
Power-off storage enable ON/OFF
1:ON
0:OFF
00154 0x0099 1 bit CH9 DI set channel
Power-off storage enable ON/OFF
1:ON
0:OFF
00155 0x009A 1 bit CH10 DI set channel
Power-off storage enable ON/OFF
1:ON
0:OFF
00156 0x009B 1 bit CH11 DI set channel
Power-off storage enable ON/OFF
1:ON
0:OFF
00157 0x009C 1 bit DIO 00
1: OUTPUT
0: INPUT (Default: INPUT)
00158 0x009D 1 bit DIO 01
1: OUTPUT
0: INPUT (Default: INPUT)
00159 0x009E 1 bit DIO 02
1: OUTPUT
0: INPUT (Default: INPUT)
00160 0x009F 1 bit DIO 03
1: OUTPUT
0: INPUT (Default: INPUT)
00161 0x00A0 1 bit DIO 04
1: OUTPUT
0: INPUT (Default: INPUT)
00162 0x00A1 1 bit DIO 05
1: OUTPUT
0: INPUT (Default: INPUT)
00163 0x00A2 1 bit DIO 06
1: OUTPUT
0: INPUT (Default: OUTPUT)
