ioLogik E2200 Series Modbus/TCP Address Mappings
I-18
Reference Address Data Type Description
00065 0x0040 1 bit CH4 DO safe pulse operate status
0: off 1: on
00066 0x0041 1 bit CH5 DO safe pulse operate status
0: off 1: on
00067 0x0042 1 bit CH6 DO safe pulse operate status
0: off 1: on
00068 0x0043 1 bit CH7 DO safe pulse operate status
0: off 1: on
00069 0x0044 1 bit CH8 DO safe pulse operate status
0: off 1: on
00070 0x0045 1 bit CH9 DO safe pulse operate status
0: off 1: on
00071 0x0046 1 bit CH10 DO safe pulse operate status
0: off 1: on
00072 0x0047 1 bit CH11 DO safe pulse operate status
0: off 1: on
00073 0x0048 1 bit CH0 DI counter status
0: off 1: on
00074 0x0049 1 bit CH1 DI counter status
0: off 1: on
00075 0x004A 1 bit CH2 DI counter status
0: off 1: on
00076 0x004B 1 bit CH3 DI counter status
0: off 1: on
00077 0x004C 1 bit CH4 DI counter status
0: off 1: on
00078 0x004D 1 bit CH5 DI counter status
0: off 1: on
00079 0x004E 1 bit CH6 DI counter status
0: off 1: on
00080 0x004F 1 bit CH7 DI counter status
0: off 1: on
00081 0x0050 1 bit CH8 DI counter status
0: off 1: on
00082 0x0051 1 bit CH9 DI counter status
0: off 1: on
00083 0x0052 1 bit CH10 DI counter status
0: off 1: on
00084 0x0053 1 bit CH11 DI counter status
0: off 1: on
00085 0x0054 1 bit CH0 DI clear count value
Read:
0: no action
Write:
1: clear counter value
0: return illegal data value
00086 0x0055 1 bit CH1 DI clear count value
Read:
0: no action
Write:
1: clear counter value
0: return illegal data value
