ioLogik E2200 Series Modbus/TCP Address Mappings
I-28
Reference Address Data Type Description
40095 0x005E 1 word CH10 DO value
0: off 1: on
40096 0x005F 1 word CH11 DO value
0: off 1: on
40097 0x0060 1 word CH0 DO power on value
0: off 1: on
40098 0x0061 1 word CH1 DO power on value
0: off 1: on
40099 0x0062 1 word CH2 DO power on value
0: off 1: on
40100 0x0063 1 word CH3 DO power on value
0: off 1: on
40101 0x0064 1 word CH4 DO power on value
0: off 1: on
40102 0x0065 1 word CH5 DO power on value
0: off 1: on
40103 0x0066 1 word CH6 DO power on value
0: off 1: on
40104 0x0067 1 word CH7 DO power on value
0: off 1: on
40105 0x0068 1 word CH8 DO power on value
0: off 1: on
40106 0x0069 1 word CH9 DO power on value
0: off 1: on
40107 0x006A 1 word CH10 DO power on value
0: off 1: on
40108 0x006B 1 word CH11 DO power on value
0: off 1: on
40109 0x006C 1 word CH0 DO safe mode value
0: off 1: on
40110 0x006D 1 word CH1 DO safe mode value
0: off 1: on
40111 0x006E 1 word CH2 DO safe mode value
0: off 1: on
40112 0x006F 1 word CH3 DO safe mode value
0: off 1: on
40113 0x0070 1 word CH4 DO safe mode value
0: off 1: on
40114 0x0071 1 word CH5 DO safe mode value
0: off 1: on
40115 0x0072 1 word CH6 DO safe mode value
0: off 1: on
40116 0x0073 1 word CH7 DO safe mode value
0: off 1: on
40117 0x0074 1 word CH8 DO safe mode value
0: off 1: on
40118 0x0075 1 word CH9 DO safe mode value
0: off 1: on
40119 0x0076 1 word CH10 DO safe mode value
0: off 1: on
40120 0x0077 1 word CH11 DO safe mode value
0: off 1: on
