ioLogik E2200 Series Modbus/TCP Address Mappings
I-54
Reference Address Data Type Description
40030 0x001D 1 word CH1 AI safe range
00: +/-150 mV
01: +/-500 mV
02: +/-5V
03: +/-10V
04: 0 to 20 mA
05: 4 to 20 mA
Other: return illegal data value
40031 0x001E 1 word CH2 AI safe range
00: +/-150 mV
01: +/-500 mV
02: +/-5V
03: +/-10V
04: 0 to 20 mA
05: 4 to 20 mA
Other: return illegal data value
40032 0x001F 1 word CH3 AI safe range
00: +/-150 mV
01: +/-500 mV
02: +/-5V
03: +/-10V
04: 0 to 20 mA
05: 4 to 20 mA
Other: return illegal data value
40033 0x0020 1 word CH4 AI safe range
00: +/-150 mV
01: +/-500 mV
02: +/-5V
03: +/-10V
04: 0 to 20 mA
05: 4 to 20 mA
Other: return illegal data value
40034 0x0021 1 word CH5 AI safe range
00: +/-150 mV
01: +/-500 mV
02: +/-5V
03: +/-10V
04: 0 to 20 mA
05: 4 to 20 mA
Other: return illegal data value
40035 0x0022 1 word CH6 AI safe range
00: +/-150 mV
01: +/-500 mV
02: +/-5V
03: +/-10V
04: 0 to 20 mA
05: 4 to 20 mA
Other: return illegal data value
