DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide

104

To view the following window, click Management > NTP > NTP Status, as shown below:

Figure 4-79 NTP Status Window

IP Source Interface

This window is used to display and configure the IP source interface settings.

To view the following window, click Management > IP Source Interface, as shown below:

Figure 4-80 IP Source Interface Window

The fields that can be configured in IP TFTP Source Interface are described below:

Parameter Description

Source Interface State

Select to enable or disable the IP TFTP source interface state here.

Interface Type

After enabling the Source Interface State option, select the interface type here.

Options to choose from are Loopback, Mgmt, and VLAN.

Interface ID

Enter the interface ID here. For loopback interfaces, this value is from 1 to 8. For

the management interface (Mgmt), this value can only be 0. For VLAN interfaces,

this value is from 1 to 4094.

Click the Apply button to accept the changes made.
