DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide

252

Parameter Description

• 6to4 - Specifies that the interface is a 6to4 tunnel interface.

• ISATAP - Specifies that the interface is an ISATAP tunnel interface.

• GRE IP - Specifies that the interface is a GRE tunnel interface. The delivery

protocol is the IPv4 protocol.

• GRE IPv6 - Specifies that the interface is a GRE tunnel interface. The

delivery protocol is the IPv6 protocol.

Source IPv4 Address

Select and enter the source IPv4 address for the tunnel interface here.

Source IPv6 Address

Select and enter the source IPv6 address for the tunnel interface here.

Destination IPv4 Address

Select and enter the destination IPv4 address for the tunnel interface here.

Destination IPv6 Address

Select and enter the destination IPv6 address for the tunnel interface here.

Network Address

Enter the network address(es) in the spaces provided here.

IPv6 Address/Prefix Length

Enter the IPv6 address and prefix length here.

Click the Apply button to accept the changes made.

Click the Back button to return to the previous window.

URPF Settings

This window is used to display and configure the Unicast Reverse Path Forwarding (URPF) settings. One common

method to initiate an attack on a network is to utilize IPv4/IPv6 source address spoofing. When using this method,

traffic is sent into the network with a source address that is known or trusted by the target. If no protection exists, the

organizational network will allow the traffic and potentially be open to a number of different attack types. Unicast RPF

helps to mitigate problems caused by malformed or forged IPv4/IPv6 source addresses passing through the router.

To view the following window, click L3 Features > URPF Settings, as shown below:

Figure 6-33 URPF Settings Window
