DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide

631

To view the following window, click Monitoring > sFlow > sFlow Sampler Settings, as shown below:

Figure 13-20 sFlow Sampler Settings Window

The fields that can be configured are described below:

Parameter Description

Unit

Select the Switch unit that will be used for this configuration here.

From Port - To Port

Select the appropriate port range used for the configuration here.

Instance

Enter the instance index number if multiple samplers are associated with one

interface. The valid range is from 1 to 65535.

Receiver

Enter the receiver index for this sampler. If not specified, the value is 0. This value

must be between 1 and 4.

Mode

Select the mode here. Options to choose from are Inbound and Outbound.

• Selecting Inbound specifies to sample ingress packets. This is the default

direction of a sampler.

• Selecting Outbound specifies to sample egress packets.

Sampling Rate

Enter packet sampling rate here. This value must be between 0 and 65536.

Entering 0 will disable this function. If not specified, the default value is 0.

Max Header Size

Enter the maximum number of bytes that should be copied from sampled packets.

This value must be between 18 and 256 bytes. By default, this value is 128 bytes.

Click the Apply button to accept the changes made.

Click the Delete button to remove the specified entry.

Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.

sFlow Poller Settings

This window is used to display and configure the sFlow poller settings.
