DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide

142

To view the following window, click L2 Features > VLAN > GVRP > GVRP Advertise VLAN, as shown below:

Figure 5-14 GVRP Advertise VLAN Window

The fields that can be configured are described below:

Parameter Description

Unit

Select the Switch unit that will be used for this configuration here.

From Port - To Port

Select the range of ports that will be used for this configuration here.

Action

Select the advertised VLAN to port mapping action here. Options to choose from

are All, Add, Remove, and Replace. When selecting All, all the advertised

VLANs will be used.

Advertise VID List

Enter the advertised VLAN ID list here.

Click the Apply button to accept the changes made.

GVRP Forbidden VLAN

This window is used to display and configure the GVRP forbidden VLAN settings.

To view the following window, click L2 Features > VLAN > GVRP > GVRP Forbidden VLAN, as shown below:

Figure 5-15 GVRP Forbidden VLAN Window
