DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide

653

The fields that can be configured are described below:

Parameter Description

Unit

Select the Switch unit that will be used for this configuration here.

SFTP Server IP

Enter the IPv4 address of the SFTP server here.

User Name

Enter the user name used for the SFTP connection here. This name can be up to

32 characters long.

Password

Enter the password used for the SFTP connection here. This password can be up

to 15 characters long.

VRF Name

Enter the name of the VRF instance here. This name can be up to 12 characters

long.

Source File

Enter the source filename and path of the configuration file located on the Switch

here. This field can be up to 64 characters long. Select the running-config option

to back up the running configuration file from the Switch. Select the startup-

config option to back up the start-up configuration file from the Switch.

Destination File

Enter the destination path and location where the configuration file should be

stored on the SFTP server. This field can be up to 64 characters long.

Click the Backup button to initiate the configuration file backup.

Certificate & Key Upgrade & Backup

Certificate & Key Upgrade from HTTP

This window is used to initiate a certificate and key upgrade from a local PC using HTTP.

To view the following window, click Tools > Certificate & Key Upgrade & Backup > Certificate & Key Upgrade

from HTTP, as shown below:

Figure 15-22 Certificate & Key Upgrade from HTTP Window

The fields that can be configured are described below:

Parameter Description

Unit

Select the Switch unit that will be used for this configuration here.

Source File

In this field the source certificate and key file’s filename and path will be displayed

after selection. To navigate to the location of the certificate and key file located on

the local PC, either double click in the text box or click the Browse button.

Destination File

Enter the destination path and location where the new certificate and key should

be stored on the Switch. This field can be up to 64 characters long.

Click the Upgrade button to initiate the certificate and key upgrade.
