DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide

290

To view the following window, click L3 Features > OSPF > OSPFv3 > OSPFv3 Redistribute Settings, as shown

below:

Figure 6-77 OSPFv3 Redistribute Settings Window

The fields that can be configured are described below:

Parameter Description

Process ID

Enter the ID for an IPv6 OSPF routing process here. It is locally assigned and

should be unique for each IPv6 OSPF routing process on the router. The range is

from 1 to 65535.

Protocol

Select the source protocol from which routes will be redistributed here. Options to

choose from are Connected, Static, RIPng, BGP, and ISIS.

Metric Type

Select the external link type associated with the default route advertised into the

IPv6 OSPF routing domain here. Options to choose from are External Type-1

and External Type-2. If a metric type is not specified, the Switch adopts a Type-2

external route. This is only for IPv6 OSPF.

Metric

Enter the metric value here. This value is used when redistributing other

processes to an IPv6 OSPF process. The range is from 0 to 16777214. The

default metric is value 20 when no metric value is specified.

Click the Apply button to accept the changes made.

Click the Find button to locate a specific entry based on the information entered.

Click the Delete button to delete the specified entry.

OSPFv3 Virtual Link Settings

This window is used to display and configure the OSPFv3 virtual link settings.
