DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide

588

11. MPLS

MPLS LDP Information Settings

MPLS LSP Trigger Information

MPLS Forwarding Settings

MPLS LDP Neighbor Password Settings

MPLS LDP Neighbor Targeted Settings

MPLS LDP Neighbor Information

MPLS Global Settings

MPLS LDP Interface Settings

MPLS LDP Session Information

MPLS LDP Statistic

MPLS LDP Binding Table

MPLS LDP Discovery Information

MPLS QoS Settings

Ping MPLS

Traceroute MPLS IPv4

MPLS LDP Information Settings

This window is used to display and configure the Multiprotocol Label Switching (MPLS) Label Distribution Protocol

(LDP) information settings.

To view the following window, click MPLS > MPLS LDP Information Settings, as shown below:

Figure 11-1 MPLS LDP Information Settings Window

The fields that can be configured are described below:

Parameter Description

LSR ID

Enter the Label Switching Router (LSR) ID here. The IPv4 address must be an

IPv4 address of an existing interface. The LSR ID is used to identify the LSR in

the MPLS network.

Select the Default option to use the default setting.

LDP Version

In this field the LDP version will be displayed.

LDP State

Select to enable or disable the LDP feature here.
