D-Link DGS-3630-28SC [254/742] Udp helper

DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide

242

The fields that can be configured are described below:

Parameter Description

Interface Null

Enter the Null interface ID here. This value can only be 0.

Description

After clicking the Edit button, enter the description for the Null interface here. This

string can be up to 64 characters long.

Click the Apply button to accept the changes made.

Click the Edit button to modify the description for the Null interface.

UDP Helper

IP Forward Protocol

This window is used to display and configure the IP forward protocol settings. This feature is used to enable the

forwarding of a specific UDP service type of packets.

To view the following window, click L3 Features > UDP Helper > IP Forward Protocol, as shown below:

Figure 6-19 IP Forward Protocol Window

The fields that can be configured are described below:

Parameter Description

IP Forward Protocol UDP

Port

Enter the destination port of the UDP service to be forwarded here. The range is

from 1 to 65535.

Click the Apply button to accept the changes made.

Click the Delete button to delete the specified entry.

Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.

IP Helper Address

This window is used to add or remove a target address for the forwarding of UDP broadcast packets. This feature

takes effect only when the received interface has an IP address assigned.
