DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide

511

Dynamic ARP Inspection

ARP Access List

This window is used to display and configure the dynamic ARP inspection settings.

To view the following window, click Security > IMPB > IPv4 > Dynamic ARP Inspection > ARP Access List, as

shown below:

Figure 9-44 ARP Access List Window

The fields that can be configured are described below:

Parameter Description

ARP Access List Name

Enter the ARP access list name used here. This name can be up to 32 characters

long.

Click the Add button to add a new entry based on the information entered.

Click the Edit button to re-configure the specific entry.

Click the Delete button to remove the specified entry.

After clicking the Edit button, the following window will appear.

Figure 9-45 ARP Access List (Edit) Window

The fields that can be configured are described below:

Parameter Description

Action

Select the action that will be taken here. Options to choose from are Permit and

Deny.

Select the type of sender IP address that will be used here. Options to choose

from are Any, Host, and IP with Mask.

Sender IP

After selecting the Host or IP with Mask options as the type of IP, enter the

sender IP address used here.

Sender IP Mask

After selecting the IP with Mask option as the type of IP, enter the sender IP
