DHCP Server Screen Prevention
Trap Name Description OID
dDhcpFilterAttackDetected When DHCP Server Screen is enabled, if the switch
received the forge DHCP Server packet, the switch will
trap the event if any attacking packet is received.
Binding objects:
(1) dDhcpFilterLogBufServerIpAddr
(2) dDhcpFilterLogBufClientMacAddr
(3) dDhcpFilterLogBufferVlanId
(4) dDhcpFilterLogBufferOccurTime
1.3.6.1.4.1.171
.14.133.0.1
DoS Prevention
Trap Name Description OID
dDosPreveAttackDetectedPacket The trap is sent when detect DOS attack.
Binding objects:
(1) dDoSPrevCtrlAttackType
(2) dDosPrevNotiInfoDropIpAddr
(3) dDosPrevNotiInfoDropPortNumber
1.3.6.1.4.1.171
.14.59.0.2
ERPS
Trap Name Description OID
dErpsFailuredetectedNotif A dErpsFailureNotification is sent when
dErpsNotificationEnabled is 'true' and a signal failure is
detected.
1.3.6.1.4.1.171
.14.78.0.1
dErpsFailureClearedNotif A dErpsFailureClearedNotif is sent when
dErpsNotificationEnabled is 'true' and a signal failure is
cleared.
1.3.6.1.4.1.171
.14.78.0.2
dErpsRPLOwnerConflictNotif A dErpsOwnerConflictNotif is sent when
dErpsNotificationEnabled is 'true' and RPL owner conflict
is detected.
1.3.6.1.4.1.171
.14.78.0.3
ErrDisable
Trap Name Description OID
dErrDisNotifyPortDisabledAssert The trap is sent when a port enters into error disabled
state.
Binding objects:
(1) dErrDisNotifyInfoPortIfIndex
(2) dErrDisNotifyInfoReasonID
1.3.6.1.4.1.171
.14.45.0.1
dErrDisNotifyPortDisabledClear The trap is sent when a port loop restarts after the interval
time.
Binding objects:
(1) dErrDisNotifyInfoPortIfIndex
(2) dErrDisNotifyInfoReasonID
1.3.6.1.4.1.171
.14.45.0.2
