DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide

539

To view the following window, click Security > Network Access Authentication > Guest VLAN, as shown below:

Figure 9-76 Guest VLAN Window

The fields that can be configured are described below:

Parameter Description

Unit

Select the Switch unit that will be used for this configuration here.

From Port - To Port

Select the appropriate port range used for the configuration here.

VID

Enter the VLAN ID used here. This value must be between 1 and 4094.

Click the Apply button to accept the changes made.

Click the Delete button to remove the specified entry.

Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.

Network Access Authentication Global Settings

This window is used to display and configure the global Network Access Authentication settings.

To view the following window, click Security > Network Access Authentication > Network Access Authentication

Global Settings, as shown below:

Figure 9-77 Network Access Authentication Global Settings Window
