DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide

300

After clicking the Please Select button, the following page will appear.

Figure 6-90 IGMP SSM Mapping Settings (Select) Window

Select the ACL and click the OK button to use the selected access list.

Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.

MLD

MLD Interface Settings

This window is used to display and configure the Multicast Listener Discovery (MLD) interface settings.

To view the following window, click L3 Features > IP Multicast Routing Protocol > MLD > MLD Interface Settings,

as shown below:

Figure 6-91 MLD Interface Settings Window

The fields that can be configured are described below:

Parameter Description

Interface VLAN

Enter the associated VLAN ID of the interface here. The range is from 1 to 4094.

Click the Find button to locate a specific entry based on the information entered.

Click the Show All button to display all the entries.

Click the Edit button to modify the specified entry.

Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
