DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide

390

To view the following window, click L3 Features > BFD > BFD Settings, as shown below:

Figure 6-204 BFD Settings Window

The fields that can be configured in BFD State are described below:

Parameter Description

BFD State

Select to globally enable or disable the BFD feature here.

Click the Apply button to accept the changes made.

The fields that can be configured in BFD Interface Settings are described below:

Parameter Description

Interface VLAN

Enter the ID of the VLAN interface that will be used here.

Click the Find button to find and display an entry based on the information entered.

Click the Edit button to configure the interval settings for the specific entry.

Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.

After clicking the Edit button, the fields that can be configured are described below:

Parameter Description

MinTxInt

Enter the minimum time interval value that the local system will use when

transmitting BFD control packets here. The range is from 50 to 1000 milliseconds.

MinRxInt

Enter the minimum time interval value between received BFD control packets that

this system is capable of supporting here. The range is from 50 to 1000

milliseconds.

Multiplier

Enter the BFD detection time multiplier value here. The range is from 3 to 99.

Slow Time

Enter the BFD slow time value here. The range is from 1000 to 3000 milliseconds.

Click the Apply button to accept the changes made.

BFD Neighbor Table

This window is used to view the BFD neighbor table.

NOTE: Performance will vary depending on the configuration and traffic patterns. It is advised to

perform lab testing before deploying BFD in a live environment.
