DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
722
Safeguard
Trap Name Description OID
dSafeguardChgToExhausted This trap indicates System change operation mode from
normal to exhaust.
Binding objects:
(1) dSafeguardEngineCurrentMode
1.3.6.1.4.1.171
.14.19.1.1.0.1
dSafeguardChgToNormal This trap indicates system change operation mode from
exhausted to normal.
Binding objects:
(1) dSafeguardEngineCurrentMode
1.3.6.1.4.1.171
.14.19.1.1.0.2
SIM
Trap Name Description OID
swSingleIPMSColdStart The commander switch will send this notification when its
member generates a cold start notification.
Binding objects:
(1) swSingleIPMSID
(2) swSingleIPMSMacAddr
1.3.6.1.4.1.171
.12.8.6.0.11
swSingleIPMSWarmStart The commander switch will send this notification when its
member generates a warm start notification.
Binding objects:
(1) swSingleIPMSID
(2) swSingleIPMSMacAddr
1.3.6.1.4.1.171
.12.8.6.0.12
swSingleIPMSLinkDown The commander switch will send this notification when its
member generates a link down notification.
Binding objects:
(1) swSingleIPMSID
(2) swSingleIPMSMacAddr
(3) ifIndex
1.3.6.1.4.1.171
.12.8.6.0.13
swSingleIPMSLinkUp The commander switch will send this notification when its
member generates a link up notification.
Binding objects:
(1) swSingleIPMSID
(2) swSingleIPMSMacAddr
(3) ifIndex
1.3.6.1.4.1.171
.12.8.6.0.14
swSingleIPMSAuthFail The commander switch will send this notification when its
member generates an authentication failure notification.
Binding objects:
(1) swSingleIPMSID
(2) swSingleIPMSMacAddr
1.3.6.1.4.1.171
.12.8.6.0.15
swSingleIPMSnewRoot The commander switch will send this notification when its
member generates a new root notification.
Binding objects:
(1) swSingleIPMSID
(2) swSingleIPMSMacAddr
1.3.6.1.4.1.171
.12.8.6.0.16
swSingleIPMSTopologyChange The commander switch will send this notification when its
member generates a topology change notification.
Binding objects:
1.3.6.1.4.1.171
.12.8.6.0.17
