DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
717
Trap Name Description OID
Binding objects:
(1) lldpStatsRemTablesInserts
(2) lldpStatsRemTablesDeletes
(3) lldpStatsRemTablesDrops
(4) lldpStatsRemTablesAgeouts
lldpXMedTopologyChangeDetected A notification generated by the local device sensing a
change in the topology that indicates that a new remote
device attached to a local port, or a remote device
disconnected or moved from one port to another.
Binding objects:
(1) lldpRemChassisIdSubtype
(2) lldpRemChassisId
(3) lldpXMedRemDeviceClass
1.0.8808.1.1.2.
1.5.4795.0.1
MAC-based Access Control
Trap Name Description OID
dMacAuthLoggedSuccess The trap is sent when a MAC-based Access Control host
is successfully logged in.
Binding objects:
(1) ifIndex
(2) dnaSessionClientMacAddress
(3) dnaSessionAuthVlan
1.3.6.1.4.1.171
.14.153.0.1
dMacAuthLoggedFail The trap is sent when a MAC-based Access Control host
login fails.
Binding objects:
(1) ifIndex
(2) dnaSessionClientMacAddress
(3) dnaSessionAuthVlan
1.3.6.1.4.1.171
.14.153.0.2
dMacAuthLoggedAgesOut The trap is sent when a MAC-based Access Control host
ages out.
Binding objects:
(1) ifIndex
(2) dnaSessionClientMacAddress
(3) dnaSessionAuthVlan
1.3.6.1.4.1.171
.14.153.0.3
MAC Notification
Trap Name Description OID
dL2FdbMacNotification This trap indicate the MAC addresses variation in the
address table.
Binding objects:
(1) dL2FdbMacChangeNotifyInfo
1.3.6.1.4.1.171
.14.3.0.1
dL2FdbMacNotificationWithVID This trap indicate the MAC addresses variation in the
address table.
Binding objects:
(1) dL2FdbMacChangeNotifyInfoWithVID
1.3.6.1.4.1.171
.14.3.0.2
