DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide

264

Parameter Description

Poison Reverse

Select to enable or disable the Poison Reverse feature here. When Poison

Reverse is enabled, the routes learned from an interface will be advertised out to

the same interface with an unreachable metric.

Split Horizon

Select to enable or disable the Split Horizon feature here. When Split Horizon is

enabled, the routes learned from an interface will be not advertised out to the

same interface.

Click the Apply button to accept the changes made.

The fields that can be configured in Redistribute Settings are described below:

Parameter Description

Protocol

Select the protocol whose routes are to be redistributed here. Options to choose

from are Connected, Static, OSPF, BGP, and ISIS. The Static option means to

redistribute IPv6 static routes. The Connected option refers to routes that are

established automatically by virtue of configuring IPv6 address on an interface.

Metric

Enter the value to be used as the metric for the redistributed routes here. The

range is from 0 to 16.

Select the Default option to use the default metric value.

Click the Apply button to accept the changes made.

Click the Delete button to delete an entry based on the information entered.

RIPng Interface Settings

This window is used to display and configure the RIPng interface settings.

To view the following window, click L3 Features > RIPng > RIPng Interface Settings, as shown below:

Figure 6-46 RIPng Interface Settings Window

The fields that can be configured are described below:

Parameter Description

Interface VLAN

Enter the VLAN interface ID here. The range is from 1 to 4094. Select the All

Interface option to use all available interfaces in this configuration.

State

Select to enable or disable the IPv6 RIP feature on the VLAN interface specified.

Metric Offset

Enter the value to be added to the metric of an IPv6 RIP route received on the

configured interface here. The range is from 1 to 16. The metric refers to the hop

count. By default, when receiving an IPv6 RIP route, a metric value of 1 is added

to the route before it is inserted into the routing table. Use this option to influence

the metric of routes received on different interfaces and influence the preference

of the route.

Select the Default option to use the default metric offset value, which is 1.
