![D-Link DGS-3630-28SC [700/742] Interface](/views2/1459303/page700/bg2bc.png)
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
688
Log Description Severity
Event Description: Dying gasp event (local).
Log Message: Device encountered an OAM dying gasp event.
Warning
Event Description: Critical event (remote).
Log Message: OAM critical event received (Port<interface-id>)
Parameters Description:
interface-id: The interface name.
Warning
Event Description: Critical event (local).
Log Message: Device encountered an OAM critical event (Port<interface-id>, <condition>)
Parameters Description:
interface-id: The interface name.
condition: Display string for the condition of generating critical link event. e.g. OAM
disable, Port shutdown, Port link down, Packet overload.
Warning
Event Description: Errored Symbol Period Event (remote).
Log Message: Errored symbol period event received (Port <interface-id>)
Parameters Description:
interface-id: The interface name.
Warning
Event Description: Errored Frame Event (remote).
Log Message: Errored frame event received(Port <interface-id>)
Parameters Description:
interface-id: The interface name.
Warning
Event Description: Errored Frame Period Event (remote).
Log Message: Errored frame period event received(Port <interface-id>)
Parameters Description:
interface-id: The interface name.
Warning
Event Description: Errored Frame Seconds Summary Event (remote).
Log Message: Errored frame seconds summary event received (Port <interface-id>)
Parameters Description:
interface-id: The interface name.
Warning
Event Description: Remote loopback start.
Log Message: OAM Remote loopback started (Port <interface-id>)
Parameters Description:
interface-id: The interface name.
Warning
Event Description: Remote loopback stop.
Log Message: OAM Remote loopback stopped (Port <interface-id>)
Parameters Description:
interface-id: The interface name.
Warning
Interface
Log Description Severity
Event Description: Port link up.
Log Message: Port <portNum> link up, <link state>
Parameters Description:
portNum: 1.Interger value;2.Represent the logic port number of the device.
link state: for ex: , 100Mbps FULL duplex.
Informational
Event Description: Port link down.
Log Message: Port <portNum> link down
Informational
