DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
675
Log Description Severity
Parameters Description:
ipaddr: TFTP Server IP address.
Event Description: This message means that Autoimage Firmware upgraded
unsuccessfully.
Log Message: The downloaded firmware was not successfully executed by DHCP
AutoImage update (TFTP Server IP: <ipaddr>)
Parameters Description:
ipaddr: TFTP Server IP address.
Informational
Auto Save
Log Description Severity
Event Description: Record the event when the configure information of DDP is saved
automatically.
Log Message:CONFIG-6-DDPSAVECONFIG: [Unit <unitID>,]Configuration automatically
saved to flash due to configuring from DDP(Username: <username>, IP: <ipaddr>)
Parameters Description:
Unit: Box ID.
username: Represent current login user.
ipaddr: Represent client IP address.
Informational
Auto Surveillance VLAN
Log Description Severity
Event Description: When a new surveillance device is detected on an interface.
Log Message: New surveillance device detected (<interface-id>, MAC: <mac-address>)
Parameters Description:
interface-id: Interface name.
mac-address: Surveillance device MAC address.
Informational
Event Description: When an interface which is enabled surveillance VLAN joins the
surveillance VLAN automatically.
Log Message: <interface-id> add into surveillance VLAN <vid>
Parameters Description:
interface-id: Interface name.
vid: VLAN ID.
Informational
Event Description: When an interface leaves the surveillance VLAN and at the same time,
no surveillance device is detected in the aging interval for that interface, the log message
will be sent.
Log Message: <interface-id> remove from surveillance VLAN <vid>
Parameters Description:
interface-id: Interface name.
vid: VLAN ID.
Informational
BGP
Log Description Severity
Event Description: BGP FSM with Peer has gone to the successfully established state.
Log Message: BGP-6-ESTABLISH: BGP connection is successfully established
Informational
