DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide

241

After clicking the Edit button, the following page will appear.

Figure 6-17 Loopback Interface (Edit) Window

The fields that can be configured are described below:

Parameter Description

State

Select to enable or disable the loopback interface here.

Description

Enter the description for the loopback interface here. This string can be up to 64

characters long.

IP Address

Enter the IPv4 address associated with this loopback interface here.

Mask

Enter the IPv4 subnet mask associated with this loopback interface here.

IPv6 Address

Enter the IPv6 address associated with this loopback interface here.

Link Local

Select this option to specify that the IPv6 address entered is the link-local IPv6

address.

Click the Back button to return to the previous window.

Click the Apply button to accept the changes made.

Click the Delete button to delete the specified entry.

Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.

Null Interface

This window is used to display and configure the Null interface settings.

To view the following window, click L3 Features > Interface > Null Interface, as shown below:

Figure 6-18 Null Interface Window
