DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide

225

To view the following window, click L2 Features > LLDP > LLDP Statistics Information, as shown below:

Figure 5-103 LLDP Statistics Information Window

The fields that can be configured are described below:

Parameter Description

Unit

Select the Switch unit that will be used here.

Port

Select the port number that will be used here.

Click the Clear Counter button to clear the counter information for the statistics displayed.

Click the Clear All button to clear all the counter information displayed.

LLDP Local Port Information

This window is used to display the information currently available for populating outbound LLDP advertisements.

To view the following window, click L2 Features > LLDP > LLDP Local Port Information, as shown below:

Figure 5-104 LLDP Local Port Information Window
