DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
697
Log Description Severity
portNum: Port ID.
Event Description: Spanning Tree loop guard blocking.
Log Message: Spanning Tree loop guard blocking(Instance: <InstanceID>, <portNum>)
Parameters Description:
InstanceID: Instance ID.
portNum: Port ID.
Informational
OSPFv2
Log Description Severity
Event Description: OSPF interface link state changed.
Log Message: OSPF interface <intf-name> changed state to [Up | Down]
Parameters Description:
intf-name: Name of OSPF interface.
Informational
Event Description: OSPF interface administrator state changed.
Log Message: OSPF protocol on interface <intf-name> changed state to [Enabled |
Disabled]
Parameters Description:
intf-name: Name of OSPF interface.
Informational
Event Description: One OSPF interface changed from one area to another.
Log Message: OSPF interface <intf-name> changed from area <area-id> to area <area-
id>
Parameters Description:
intf-name: Name of OSPF interface.
area-id: OSPF area ID.
Informational
Event Description: One OSPF neighbor state changed from Loading to Full.
Log Message: OSPF nbr <nbr-id> on interface <intf-name> changed state from Loading to
Full
Parameters Description:
intf-name: Name of OSPF interface.
nbr-id: Neighbor's router ID.
Notice
Event Description: One OSPF neighbor state changed from Full to Down.
Log Message: OSPF nbr <nbr-id> on interface <intf-name> changed state from Full to
Down
Parameters Description:
intf-name: Name of OSPF interface.
nbr-id: Neighbor's router ID.
Notice
Event Description: One OSPF neighbor state’s dead timer expired.
Log Message: OSPF nbr <nbr-id> on interface <intf-name> dead timer expired
Parameters Description:
intf-name: Name of OSPF interface.
nbr-id: Neighbor's router ID.
Notice
Event Description: One OSPF virtual neighbor state changed from Loading to Full.
Log Message: OSPF nbr <nbr-id> on virtual link changed state from Loading to Full
Parameters Description:
nbr-id: Neighbor's router ID.
Notice
Event Description: One OSPF virtual neighbor state changed from Full to Down.
Log Message: OSPF nbr <nbr-id> on virtual link changed state from Full to Down
Notice
