DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
658
To view the following window, click Tools > Certificate & Key Upgrade & Backup > Certificate & Key Backup to
TFTP, as shown below:
Figure 15-28 Certificate & Key Backup to TFTP Window
The fields that can be configured are described below:
Parameter Description
Unit
Select the Switch unit that will be used for this configuration here.
TFTP Server IP
Enter the TFTP server IP address here. When select the IPv4 option, enter the
IPv4 address of the TFTP server in the space provided. When the IPv6 option is
selected, enter the IPv6 address of the TFTP server in the space provided.
VRF Name
Enter the name of the VRF instance here. This name can be up to 12 characters
long.
Source File
Enter the source filename and path of the certificate and key file located on the
Switch here. This field can be up to 64 characters long.
Destination File
Enter the destination filename and path of the certificate and key file to be backed
up to the TFTP server here. This field can be up to 64 characters long.
Click the Backup button to initiate the certificate and key backup.
Certificate & Key Backup to FTP
This window is used to initiate a certificate and key backup to an FTP server.
To view the following window, click Tools > Certificate & Key Upgrade & Backup > Certificate & Key Backup to
FTP, as shown below:
Figure 15-29 Certificate & Key Backup to FTP Window
