DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide

594

To view the following window, click MPLS > MPLS LDP Neighbor Targeted Settings, as shown below:

Figure 11-5 MPLS LDP Neighbor Targeted Settings Window

The fields that can be configured are described below:

Parameter Description

Neighbor Targeted

Enter the LSR ID of the targeted peer here. The targeted peer is used to establish

the LDP session with the non-directly connected neighbor.

Targeted Hello Interval

Enter the interval to the hello message for sessions with extended peers here.

The range is from 5 to 65535 seconds.

Select the Default option to use the default value.

Targeted Hello Hold Time

Enter the hold-time of the hello messages for sessions with extended peers here.

The range is from 15 to 65535 seconds.

Select the Default option to use the default value.

Targeted Hello Source

Address Type

Select the target hello source address type here. Options to choose from are:

• Interface - Specifies that the IP address of each interface is used as the

hello-source address.

• Router ID - Specifies that the router ID (LSR ID) is used as the hello-

source address.

• IP Address - Specifies to enter the IP address that will be used as the

hello-source address.

Targeted Hello Source

Address

After selecting IP Address as the type, enter the IP address that will be used as

the hello-source address here.

Click the Apply button to accept the changes made.

Click the Delete button to remove the specific entry.

Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.

MPLS LDP Neighbor Information

This window is used to view and clear the MPLS LDP neighbor information.
