DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide

657

The fields that can be configured are described below:

Parameter Description

Unit

Select the Switch unit that will be used for this configuration here.

SFTP Server IP

Enter the IPv4 address of the SFTP server here.

User Name

Enter the user name used for the SFTP connection here. This name can be up to

32 characters long.

Password

Enter the password used for the SFTP connection here. This password can be up

to 15 characters long.

VRF Name

Enter the name of the VRF instance here. This name can be up to 12 characters

long.

Source File

Enter the source filename and path of the certificate and key file located on the

SFTP server here. This field can be up to 64 characters long.

Destination File

Enter the destination path and location where the new certificate and key should

be stored on the Switch. This field can be up to 64 characters long.

Click the Upgrade button to initiate the certificate and key upgrade.

Certificate & Key Backup to HTTP

This window is used to initiate a certificate and key backup to a local PC using HTTP.

To view the following window, click Tools > Certificate & Key Upgrade & Backup > Certificate & Key Backup to

HTTP, as shown below:

Figure 15-27 Certificate & Key Backup to HTTP Window

The fields that can be configured are described below:

Parameter Description

Unit

Select the Switch unit that will be used for this configuration here.

Source File

Enter the source filename and path of the certificate and key file located on the

Switch here. This field can be up to 64 characters long.

Click the Backup button to initiate the certificate and key backup.

Certificate & Key Backup to TFTP

This window is used to initiate a certificate and key backup to a TFTP server.
