DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide

596

The fields that can be configured for MPLS Interface Settings are described below:

Parameter Description

Interface VID

Enter the interface VLAN ID that will be used here. The range is from 1 to 4094.

MPLS State

Select to enable or disable the MPLS feature for the specified interface here.

Click the Apply button to accept the changes made.

Click the Find button to locate a specific entry based on the information entered.

Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.

MPLS LDP Interface Settings

This window is used to display and configure the MPLS LDP interface settings.

To view the following window, click MPLS > MPLS LDP Interface Settings, as shown below:

Figure 11-8 MPLS LDP Interface Settings Window

The fields that can be configured are described below:

Parameter Description

Interface VID

Enter the interface VLAN ID used here. The range is from 1 to 4094.

LDP State

Select to enable or disable the LDP feature on the specified interface here.

Discovery Accept

Select to enable or disable the discovery accept feature here. If targeted hello

message acceptance is disabled in the interface, and if the received targeted

hello is not coming from the local configured targeted peer, the message will be

ignored. If targeted hello message acceptance is enabled in the interface, LSR

will honor the received targeted hello messages sent by all neighbors.

Distribution Mode

Select the distribution mode here. Options to choose from are:

• DU - Specifies the downstream unsolicited distribution mode.

• DoD - Specifies the downstream on-demand distribution mode.

Discovery Hello Interval

Enter the discovery hello interval value here. The range is from 1 to 65535

seconds.

Select the Default option to use the default value.

Discovery Hello Hold Time

Enter the discovery hello hold-time value here. The range is from 5 to 65535
