DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide

557

Parameter Description

Destination File Name

Enter the destination file name used here. This name can be up to 32 characters

long.

Click the Apply button to accept the changes made.

Crypto PKI Trustpoint

This window is used to display and configure the crypto PKI trust point settings.

To view the following window, click Security > SSL > Crypto PKI Trustpoint, as shown below:

Figure 9-98 Crypto PKI Trustpoint Window

The fields that can be configured are described below:

Parameter Description

Trustpoint

Enter the name of the trust-point that is associated with the imported certificates

and key pairs here. This name can be up to 32 characters long.

File System Path

Enter the file system path for certificates and key pairs here.

Password

Enter the encrypted password phrase that is used to undo encryption when the

private keys are imported here. The password phrase is a string of up to 64

characters. If the password phrase is not specified, the NULL string will be used.

TFTP Server Path

Enter the TFTP server path here.

Type

Select the type of certificate that will be imported here. Options to choose from

are Both, CA, and Local.

• Selecting Both specifies to import the CA certificate, local certificate and key

pairs.

• Selecting CA specifies to import the CA certificate only.

• Selecting Local specifies to import local certificate and key pairs only.

Click the Apply button to accept the changes made.

Click the Find button to locate a specific entry based on the information entered.

Click the Delete button to remove the specified entry.

SSL Service Policy

This window is used to display and configure the SSL service policy settings.
