DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide

281

The fields that can be configured are described below:

Parameter Description

Process ID

Enter the OSPF process ID here. The range is from 1 to 65535.

Interface Name

Enter the name of the interface that will be used in the results here.

Neighbor

Enter the neighbor ID here.

Click the Find button to locate a specific entry based on the information entered.

Click the Show Detail button to view more detailed information for the specified entry.

Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.

After clicking the Show Detail button, the following page will appear.

Figure 6-66 OSPFv2 Neighbor Table (Show Detail) Window

Click the Back button to return to the previous window.

OSPFv2 Host Route Settings

This window is used to display and configure the OSPFv2 host route settings. The router will advertise specific host

routes as router LSAs for a stub link.

To view the following window, click L3 Features > OSPF > OSPFv2 > OSPFv2 Host Route Settings, as shown

below:

Figure 6-67 OSPFv2 Host Route Settings Window
