DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
319
Click the Add button to add a new entry based on the information entered.
Click the Delete button to delete an entry based on the information entered.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
After clicking the Show List button, the following page will appear.
Figure 6-113 PIM RP Candidate (Show List) Window
The fields that can be configured are described below:
Parameter Description
ACL Type
Select the ACL type that will be used to display the type of existing access lists in
the table here. Options to choose from are IP ACL, Expert IP ACL, IPv6 ACL,
Expert IPv6 ACL, MAC ACL, and Expert ACL.
ACL List
Select the radio button of the access list in the table that will be used here.
Click the Find button to display a list of access lists based on the selection made.
Click the Show All button to display all configured access lists.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
Click the Apply button to use the selected access list.
PIM RP Table
This window is used to find and display PIM RP information.
To view the following window, click L3 Features > IP Multicast Routing Protocol > PIM > PIM for IPv4 > PIM RP
Table, as shown below:
Figure 6-114 PIM RP Table Window
