DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide

135

After selecting the MAC Address VLAN Learning Settings tab option, at the top of the page, the following page will

be available.

Figure 5-5 MAC Address Table Settings (MAC Address VLAN Learning Settings) Window

The fields that can be configured are described below:

Parameter Description

VID List

Enter the VLAN ID(s) that will be used in this configuration or display here. A

series of VLAN IDs can be entered separated by commas or a range of VLAN IDs

can be entered separated by a hyphen.

Status

Select to enable or disable the MAC address learning function on the VLAN(s)

specified here.

Click the Apply button to accept the changes made.

Click the Find button to locate a specific entry based on the information entered.

Click the Show All button to display all the available entries.

Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.

MAC Address Table

This window is used to view the entries listed in the MAC address table.
