DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide

651

To view the following window, click Tools > Configuration Restore & Backup > Configuration Backup to FTP, as

shown below:

Figure 15-19 Configuration Backup to FTP Window

The fields that can be configured are described below:

Parameter Description

Unit

Select the Switch unit that will be used for this configuration here.

FTP Server IP

Enter the FTP server IP address here. When select the IPv4 option, enter the

IPv4 address of the FTP server in the space provided. When the IPv6 option is

selected, enter the IPv6 address of the FTP server in the space provided.

TCP Port

Enter the TCP port number used for the FTP connection here. The range is from

1 to 65535.

User Name

Enter the user name used for the FTP connection here. This name can be up to

32 characters long.

Password

Enter the password used for the FTP connection here. This password can be up

to 15 characters long.

VRF Name

Enter the name of the VRF instance here. This name can be up to 12 characters

long.

Source File

Enter the source filename and path of the configuration file located on the Switch

here. This field can be up to 64 characters long. Select the running-config option

to back up the running configuration file from the Switch. Select the startup-

config option to back up the start-up configuration file from the Switch.

Destination File

Enter the destination path and location where the configuration file should be

stored on the FTP server. This field can be up to 64 characters long.

Click the Backup button to initiate the configuration file backup.

Configuration Backup to RCP

This window is used to initiate a configuration file backup to an RCP server.
