DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide

595

To view the following window, click MPLS > MPLS LDP Neighbor Information, as shown below:

Figure 11-6 MPLS LDP Neighbor Information Window

The fields that can be configured are described below:

Parameter Description

Peer

Enter the IP address which is used as the peer LSR ID here.

Click the Find button to locate a specific entry based on the information entered.

Click the Clear by Peer button to clear the information related to the peer entered.

Click the Clear All button to clear all the MPLS LDP neighbor information.

MPLS Global Settings

This window is used to display and configure the global MPLS settings.

To view the following window, click MPLS > MPLS Global Settings, as shown below:

Figure 11-7 MPLS Global Settings Window

The fields that can be configured for MPLS Global Settings are described below:

Parameter Description

MPLS Global State

Select to globally enable or disable the MPLS feature here.

LSP Trap State

Select to enable or disable the MPLS LSP trap feature here.

Click the Apply button to accept the changes made.
