DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
685
DHCPv6 Relay
Log Description Severity
Event Description: DHCPv6 relay on a specify interface’s administrator state changed.
Log Message: DHCPv6 relay on interface <ipif-name> changed state to [enabled |
disabled]
Parameters Description:
<ipif-name>: Name of the DHCPv6 relay agent interface.
Informational
DHCPv6 Server
Log Description Severity
Event Description: The address of the DHCPv6 Server pool is used up.
Log Message: The address of the DHCPv6 Server pool <pool-name> is used up
Parameters Description:
<pool-name>: Name of the DHCPv6 Server pool.
Informational
Event Description: The number of allocated IPv6 addresses is equal to 4096.
Log Message: The number of allocated ipv6 addresses of the DHCPv6 Server pool is
equal to 4096
Informational
DLMS
Log Description Severity
Event Description: Input an illegal activation code.
Log Message: Illegal activation code (AC: <string25>)
Parameters Description:
<string25>: Activation Code.
Informational
Event Description: License Expired.
Log Message: License expired (license:<license-model>, AC: <string25>)
Parameters Description:
<license-model>: License Model Name.
<string25>: Activation Code.
Critical
Event Description: License successfully installed.
Log Message: License successfully installed (license:<license-model>, AC: <string25>)
Parameters Description:
<license-model>: License Model Name.
<string25>: Activation Code.
Informational
Event Description: The Activation Code is unbound.
Log Message: Unbound Activation Code (AC: <string25>)
Parameters Description:
<string25>: Activation Code.
Critical
Event Description: When a license is going to expire, it will be logged before 30 days.
Log Message: License will expire in 30 days. (license:<license-model>, AC: <string25>)
Parameters Description:
<license-model>: License Model Name.
<string25>: Activation Code.
Informational
