DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide

610

The fields that can be configured for Create L2VC Interface Description are described below:

Parameter Description

L2VC Interface Name

Enter the L2VC interface name here. This name can be up to 64 characters long.

Description

Enter the L2VC interface description here. This name can be up to 64 characters

long.

Click the Apply button to accept the changes made.

The fields that can be configured for Find L2VC Interface Description are described below:

Parameter Description

L2VC Interface Name

Enter the L2VC interface name here. This name can be up to 64 characters long.

Click the Find button to locate a specific entry based on the information entered.

Click the Show All button to display all the available entries.

Click the Delete Description button to delete the description for the specific entry.

Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.

VPLS Settings

This window is used to display and configure the Virtual Private LAN Service (VPLS) settings.

To view the following window, click MPLS L2VPN > VPLS Settings, as shown below:

Figure 12-5 VPLS Settings Window

The fields that can be configured for VPLS Settings are described below:

Parameter Description

VPLS Name

Enter the VPLS instance name here. This name can be up to 32 characters long.

VPLS Type

Select the VPLS type here. Options to choose from are:

• Manual - Specifies to manually configure neighbors and use LDP for

signaling.

• Autodiscovery - Specifies to use BGP for auto-discovery and signaling.

Click the Apply button to accept the changes made.

Click the Find button to locate a specific entry based on the information entered.
