DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
721
Trap Name Description OID
Binding objects:
(1) ifIndex
(2) ifAdminStatus
(3) ifOperStatus
5.3
Port Security
Trap Name Description OID
dPortSecMacAddrViolation When the port security trap is enabled, new MAC
addresses that violate the pre-defined port security
configuration will trigger trap messages to be sent out.
Binding objects:
(1) ifIndex
(2) dPortSecIfCurrentStatus
(3) dPortSecIfViolationMacAddress
1.3.6.1.4.1.171
.14.8.0.1
Reboot Schedule
Trap Name Description OID
agentRebootIn5Min This trap is sent when the countdown equals 5 minutes. 1.3.6.1.4.1.171
.14.170.0.1
agentRebootIn1Min This trap is sent when the countdown equals1 minute. 1.3.6.1.4.1.171
.14.170.0.2
RMON
Trap Name Description OID
risingAlarm The SNMP trap that is generated when an alarm entry
crosses its rising threshold and generates an event that is
configured for sending SNMP traps.
Binding objects:
(1) alarmIndex
(2) alarmVariable
(3) alarmSampleType
(4) alarmValue
(5) alarmRisingThreshold
1.3.6.1.2.1.16.
0.1
fallingAlarm The SNMP trap that is generated when an alarm entry
crosses its falling threshold and generates an event that
is configured for sending SNMP traps.
Binding objects:
(1) alarmIndex
(2) alarmVariable
(3) alarmSampleType
(4) alarmValue
(5) alarmFallingThreshold
1.3.6.1.2.1.16.
0.2
