DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide

359

Parameter Description

BGP. This includes Type-1 and Type-2 routes.

• Internal+E1 - Specifies to redistribute only the OSPF AS-external Type-1

and OSPF AS-internal routes.

• Internal+E2 - Specifies to redistribute only the OSPF AS-external Type-2

and OSPF AS-internal routes.

• Internal - Specifies to redistribute only the OSPF AS-internal routes.

• External Type-1 - Specifies to redistribute only the OSPF AS-external Type-

1 routes.

• External Type-2 - Specifies to redistribute only the OSPF AS-external Type-

2 routes.

Metric

Enter the BGP metric value for the redistributed routes here. The range is from 0

to 4294967295.

Route Map Name

Enter the route map name, used to filter the networks to be redistributed, here.

This name can be up to 16 characters long.

Click the Apply button to accept the changes made.

Click the Edit button to re-configure the specific entry.

Click the Delete button to remove the specific entry.

Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.

After clicking the Please Select button, the following page will appear.

Figure 6-166 BGP Route Redistribution Settings (Please Select) Window

Select the VRF entry and click the OK button to use the selected VRF entry.

Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.

BGP Route Preference Settings

This window is used to display and configure the BGP route preference settings.

To view the following window, click L3 Features > BGP > BGP Route Preference Settings, as shown below:

Figure 6-167 BGP Route Preference Settings Window
