DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide

245

To view the following window, click L3 Features > IPv4 Static Route BFD, as shown below:

Figure 6-22 IPv4 Static Route BFD Window

The fields that can be configured are described below:

Parameter Description

Interface Name

Enter the name of the interface that will be used to create the BFD session here.

This name can be up to 12 characters long.

IP Address

Enter the IP address of the BFD peer here.

Click the Apply button to accept the changes made.

Click the Delete button to remove the specific entry.

Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.

IPv4 Route Table

This window is used to display and configure the IPv4 route table settings.

To view the following window, click L3 Features > IPv4 Route Table, as shown below:

Figure 6-23 IPv4 Route Table Window

The fields that can be configured are described below:

Parameter Description

VRF Name

Enter the name of the VRF instance here. This name can be up to 12 characters

long.

IP Address

Select and enter the single IPv4 address here.

Network Address

Select and enter the IPv4 network address here. In the first space enter the

network prefix and in the second space enter the network mask.
