DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide

513

Parameter Description

validity of IP address in the ARP payload. The sender IP in both the ARP request

and response and target IP in the ARP response are validated. Packets destined

for the IP addresses 0.0.0.0, 255.255.255.255, and all IP multicast addresses are

dropped. Sender IP addresses are checked in all ARP requests and responses,

and target IP addresses are checked only in ARP responses.

Click the Apply button to accept the changes made.

The fields that can be configured in ARP Inspection Filter are described below:

Parameter Description

ARP Access List Name

Enter the ARP access list name used here. This name can be up to 32 characters

long.

VID List

Enter the VLAN ID list used here.

Static ACL

Select whether to use a static ACL or not here by either selecting Yes or No.

Click the Add button to add a new entry based on the information entered.

Click the Delete button to remove an entry based on the information entered.

Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.

ARP Inspection Port Settings

This window is used to display and configure the ARP inspection port settings.

To view the following window, click Security > IMPB > IPv4 > Dynamic ARP Inspection > ARP Inspection Port

Settings, as shown below:

Figure 9-47 ARP Inspection Port Settings Window

The fields that can be configured are described below:

Parameter Description

Unit

Select the Switch unit that will be used for this configuration here.

From Port - To Port

Select the appropriate port range used for the configuration here.

Rate Limit

Enter the rate limit value here. This value must be between 1 and 150 packets per

seconds.

Burst Interval

Enter the burst interval value here. This value must be between 1 and 15. Tick the
