![D-Link DGS-3630-28SC [699/742] Ethernet oam](/views2/1459303/page699/bg2bb.png)
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
687
Log Description Severity
vlanid: VLAN ID.
interface-id: Interface name.
ERPS
Log Description Severity
Event Description: manual switch is issued.
Log Message: "Manual switch is issued on node (MAC: <macaddr>, instance
<InstanceID>)"
Parameters Description:
macaddr: MAC address.
InstanceID: Instance ID.
Warning
Event Description: signal fail is detected.
Log Message: "Signal fail detected on node (MAC: <macaddr>, instance <InstanceID>)"
Parameters Description:
macaddr: MAC address.
InstanceID: Instance ID.
Warning
Event Description: Signal fail cleared.
Log Message: "Signal fail cleared on node(MAC: <macaddr>, instance <InstanceID>)"
Parameters Description:
macaddr: MAC address.
InstanceID: Instance ID.
Warning
Event Description: Force switch is issued.
Log Message: "Force switch is issued on node (MAC: <macaddr>, instance
<InstanceID>)"
Parameters Description:
macaddr: MAC address.
InstanceID: Instance ID.
Warning
Event Description: Clear command is issued.
Log Message: "Clear command is issued on node (MAC: <macaddr>, instance
<InstanceID>)"
Parameters Description:
macaddr: MAC address.
InstanceID: Instance ID.
Warning
Event Description: "RPL owner conflicted.
Log Message: "RPL owner conflicted on the node (MAC: <macaddr>, instance
<InstanceID>)"
Parameters Description:
macaddr: MAC address.
InstanceID: Instance ID.
Warning
Ethernet OAM
Log Description Severity
Event Description: Dying gasp event (remote).
Log Message: OAM dying gasp event received (Port<interface-id>)
Parameters Description:
interface-id: The interface name.
Warning
