DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide

396

Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.

ISIS Router Settings

This window is used to display and configure the ISIS router settings.

To view the following window, click L3 Features > ISIS > ISIS Router Settings, as shown below:

Figure 6-211 ISIS Router Settings (IPv4) Window

Figure 6-212 ISIS Router Settings (IPv6) Window

The fields that can be configured are described below:

Parameter Description

Protocol

Select the protocol that will be used here. Options to choose from are IPv4 and

IPv6.

Area Tag

Enter the ISIS area tag here. This specifies the tag of a routing process in which

the IP interface is enabled. This can be up to 16 characters long.

Adjacency Check

Select to enable or disable the adjacency check feature here. ISIS performs

consistency checks on hello packets and forms an adjacency only with a

neighboring router that supports the same set of protocols. This is used to enable
