DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
706
Log Description Severity
Parameters Description:
vc_id: The link standby pseudo wire ID.
ipaddr: The peer ip address of the link standby pseudo wire.
VRRP Debug
Log Description Severity
Event Description: One virtual router state becomes Master.
Log Message: VR <vr-id> at interface <intf-name> switch to Master
Parameters Description:
vr-id: VRRP virtual router ID.
intf-name: Interface name on which virtual router is based.
Informational
Event Description: One virtual router state becomes Backup.
Log Message: VR <vr-id> at interface <intf-name> switch to Backup
Parameters Description:
vr-id: VRRP virtual router ID.
intf-name: Interface name on which virtual router is based.
Informational
Event Description: One virtual router state becomes Init.
Log Message: VR <vr-id> at interface <intf-name> switch to Init
Parameters Description:
vr-id: VRRP virtual router ID.
intf-name: Interface name on which virtual router is based.
Informational
Event Description: Authentication type mismatch of one received VRRP advertisement
message.
Log Message: Authentication type mismatch on VR <vr-id> at interface <intf-name>
Parameters Description:
vr-id: VRRP virtual router ID.
intf-name: Interface name on which virtual router is based.
Warning
Event Description: Authentication checking fail of one received VRRP advertisement
message.
Log Message: Authentication fail on VR <vr-id> at interface <intf-name>. Auth type <auth-
type>
Parameters Description:
vr-id: VRRP virtual router ID.
intf-name: Interface name on which virtual router is based.
Auth-type: VRRP interface authentication type.
Warning
Event Description: Checksum error of one received VRRP advertisement message.
Log Message: Received an ADV msg with incorrect checksum on VR <vr-id> at interface
<intf-name>
Parameters Description:
vr-id: VRRP virtual router ID.
intf-name: Interface name on which virtual router is based.
Warning
Event Description: Virtual router ID mismatch of one received VRRP advertisement
message.
Log Message: Received ADV msg virtual router ID mismatch. VR <vr-id> at interface
<intf-name>
Parameters Description:
vr-id: VRRP virtual router ID.
intf-name: Interface name on which virtual router is based.
Warning
