DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
543
Click the Clear All button to clear all the information in this table.
Click the Find button to locate a specific entry based on the information entered.
Click the Show All button to locate and display all the entries.
Safeguard Engine
Periodically, malicious hosts on the network will attack the Switch by utilizing packet flooding (ARP Storm) or other
methods. These attacks may increase the Switch’s CPU load beyond its capability. To alleviate this problem, the
Safeguard Engine function was added to the Switch’s software.
The Safeguard Engine can help the overall operability of the Switch by minimizing the workload of the Switch while the
attack is ongoing, thus making it capable to forward essential packets over its network in a limited bandwidth.
If the CPU load rises above the rising threshold value, the Safeguard Engine function will be activated and the Switch
will enter the exhausted mode. In the exhausted mode, the Switch will limit the bandwidth available for ARP and
broadcast IP packets. If the CPU load falls below the falling threshold value, the Safeguard Engine will be deactivated
and the Switch will exit the exhausted mode and enter the normal mode.
Packets that are destined to the CPU can be classified into three groups. These groups, otherwise known as sub-
interfaces, are logical interfaces that the CPU will use to identify certain types of traffic. The three groups are Protocol,
Manage, and Route. Generally, the Protocol group should receive the highest priority when the Switch’s CPU
processes received packets and the Route group should receive the lowest priority as the Switch’s CPU usually does
get involved in the processing of routing packets. In the Protocol group, packets are protocol control packets
identified by the router. In the Manage group, packets are destined to any router or system network management
interface by means of interactive access protocols, like Telnet and SSH. In the Route group, packets are identified as
traversing routing packets that is generally processed by the router CPU.
In the following table a list of supported protocols are displayed with their respective sub-interfaces (groups):
Protocol Name Sub-interface
(Group)
Description
802.1X
Protocol Port-based Network Access Control
ARP
Protocol Address resolution Protocol
BGP
Protocol Border Gateway Protocol
DHCP
Protocol Dynamic Host Configuration Protocol
DNS
Protocol Domain Name System
DVMRP
Protocol Distance Vector Multicast Routing Protocol
GVRP
Protocol GARP VLAN Registration Protocol
ICMPv4
Protocol Internet Control Message Protocol
ICMPv6-
Neighbor
Protocol IPv6 Internet Control Message Protocol Neighbor Discovery Protocol
(NS/NA/RS/RA)
ICMPv6-Other
Protocol IPv6 Internet Control Message Protocol except Neighbor Discovery
Protocol (NS/NA/RS/RA)
IGMP
Protocol Internet Group Management Protocol
LACP
Protocol Link Aggregation Control Protocol
NTP
Protocol Network Time Protocol
OSPF
Protocol Open Shortest Path First
PIM
Protocol Protocol Independent Multicast
PPPoE
Protocol Point-to-point protocol over Ethernet
RIP
Protocol Routing Information Protocol
SNMP
Manage Simple Network Management Protocol
